TH55B HD BIOS Manual
13
Hardware Health Configuration
This item shows the system temperature, fan speed, and voltage information.
Advanced
Hardware Health Configuration
H/W Health Function [Enabled]
Shutdown Temperature [Disabled]
CPU Temperature
PCH
CPU FAN
System1 FAN
System2 FAN
+12.0V
CPU Vcore
CPU VTT Voltage
DRAM Voltage
3.30V SB
Temperature
System
+5.00V
Temperature
BIOS SETUP UTILITY
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Enables Hardware
Health Monitoring
Device.
H/W Health Function
If with a monitoring system, the system will show PC health status during POST stage.
Options: Enabled (Default) / Disabled
Shutdown Temperature
This item allows you to set up the CPU shutdown Temperature. This item is only
effective under Windows 98 ACPI mode.
Options: Disabled (Default) / 60 /140 / 65 /149 / ℃℉℃℉70 /158℃℉ / 75 /℃ 167 ℉
/ 80 /℃ 176 / 85 /℉℃185 / 90 /℉℃194℉
