TH55B HD BIOS Manual
20
MPS Revision
The BIOS supports version 1.1 and 1.4 of the Intel multiprocessor specification.
Select version supported by the operating system running on this computer.
Option: 1.4 (Default) / 1.1
MPS and ACPI MADT ordering
Modern ordering is for Windows XP or later OSes. Legacy ordering is for Windows
2000 or earlier OSes.
Option: Modern ordering (Default) / Legacy ordering
PCI Express Configuration
BIOS SETUP UTILITY
Advanced
vxx.xx (C)Copyright 1985-200x, Amer ican Megatre nds, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
PCI Express Configuration
Active State Power-Management [Disabled]
Enable/Disable
PCI Express L0s and
L1 link power
states.
Active State Power-Management
Enable or disable PCI Express L0s and L1 link power states.
Option: Disabled (Default) / Enabled
