Biostar G41 DVI Версия 6.x [11/47] B memory capacity

G41 DVI

B. Memory Capacity

DIMM Socket

Location

DDR2 Module

Total Memory

Size

DDR2_A1 256MB/512MB/1GB/2GB/4GB

DDR2_B1 256MB/512MB/1GB/2GB/4GB

Max is 8GB.

C. Dual Channel Memory Installation

Please refer to the following requirements to activate Dual Channel function:

Install memory module of the same density in pairs, shown in the table.

Dual Channel Status

DDR2_A1

DDR2_B1

Disabled O X

Disabled X O

Enabled O O

(O means memory installed; X, not installed.)

The DRAM bus width of the memory module must be the same(x8 or

x16)
