Biostar G41 DVI Версия 6.x [7/47] Chapter 2 hardware installation

G41 DVI

CHAPTER 2: HARDWARE INSTALLATION

2.1 I

NSTALLING CENTRAL PROCESSING UNIT (CPU)

Special Notice:

Remove Pin Cap before installation, and make good preservation

for future use. When the CPU is removed, cover the Pin Cap on the

empty socket to ensure pin legs won’t be damaged.

Pin-Cap

Step 1: Pull the socket locking lever out from the socket and then raise

the lever up to a 90-degree angle.
