G41 DVI
39
SPEC
Złącze napędu dyskietek x1 Każde złącze obs ługuje 2 napędy dyskietek
Złącze Port drukarki x1 Każde złącze obs ługuje 1 Port drukarki
Port szeregowy x1
Złącze IDE x1 Każde złącze obs ługuje 2 urządzenia IDE
Złącze SATA x4 Każde złącze obs ługuje 1 urządzenie SATA
Złącze panela przedniego x1 Obsługa elementów panela przedniego
Przednie złącze audio x1 Obsługa funkcji audio na panelu przednim
Złącze wejścia CD x1 Obsługa funkcji wejścia aud io CD
Złącze wyjścia S/PDIF x1 Obsługa funkcji cyfrowego wyjścia aud io
Złącze główkowe wentylatora
procesora x1
Zasilanie wentylatora procesora (z funkcją Smart Fan)
Złącze główkowe wentylatora
systemowego x1
Zasilanie wentylatora systemowego
Złącze główkowe kasowania CMOS x1
Złącze USB x2
Każde złącze obs ługuje 2 porty USB na panelu
przednim
Złącze zasilania (24 pinowe) x1
Złącza
wbudowane
Złącze zas ilania (4 p ino we) x1
Back Panel
I/O
Klawiatura PS/2 x1
Mysz PS /2 x1
Port VGA x1
Port DVI-D x1
Port LAN x1
Port USB x4
Gniazdo audio x3
Wymiary
płyty
190mm (S) X 244 mm (W)
Obsluga
systemu
operacyjne
go
Windows 2000 / XP / Vista 32 / Vista 64
Biostar zastrzega sobie prawo dodawania lub
odwoływania obsług i dowo ln ego systemu
operacyjnego b ez powiadomienia.
