Motherboard Manual
4
1.5 MOTHERBOARD LAYOUT
KBMS1
VGA1
USB1
RJ45USB1
AUDIO1
ATXPWR2
DVI1
JUSBV1
F_AUDIO1
CD_IN1
SPDIF1
F_COM1
Super
I/O
LAN
Codec
F_PRINT1
FDD1
BAT1
PEX16_1
PCI1
PCI2
SYS_FAN1
JUSBV2
F_USB1 F_USB2 PANEL1
SATA2
SATA1
SATA3
SATA4
BIOS
JCMOS1
IDE1
ATXPWR1
DDR2_B1
DDR2_A1
CPU_FAN1
Intel
G41
Intel
ICH7
LGA775
CPU1
Note: ■ represents the 1
st
pin.
