Motherboard Manual
36
PORTUGUESE
ESPECIFICAÇÕES
CPU
LGA 775
Processador Intel Core2Duo / Core2Quad
/ Pent ium Dual-Core / C eleron Dual-Core /
Celeron 4xx
(Watt máximo: 95W )
Suporta as tecnolog ias Hyper-Thread ing / Execut e
Disable B it / Enhanced Intel SpeedStep® / Intel
Arquitecture -64 / Extended Memory 64 / Virtualization
FSB
800 / 1066 / 1333 MHz
Chipset
Intel G41
Intel ICH7
Especificaçã
o Super I/O
ITE 8718F
Proporciona as funcionalidades mais
utilizadas em termos da especificação
Super I/O.
Interface LPC (Low Pin Count).
In iciat iv as par a contro lo do amb iente
Monitoriz ação do hardware
Controlador/Monitor da velocidade da ventoinha
Função "S mart Gu ard ian" d a ITE
Memória
principal
Ranhuras DIMM DDR3 x 2
Cada módulo DIMM suporta uma
memória DDR3 de 256 MB / 512 MB / 1GB
/ 2GB
Capacidad e máx ima d e memória:4 GB
Módulo de memória DDR3 de canal duplo
Suporta módulos DDR3 800/1066/1333(OC)
Os módulos DIMM registados e os DIMM ECC não são
suportados
(CPU com FSB 800 MHz só suporta DDR3 800)
Placa
gráfica
GMA X4500 Memória de vídeo máxima partilhada: 256 MB
IDE
Controlador IDE integrado
Modo Bus master Ultra DMA 33 / 66 / 100
Suporta o modo PIO 0~4,
SATA
Controlador Serial ATA integrado
Velocidades de transmissão de dados até 3.0 Gb/s.
Compat ibilidade com a especificação SATA versão 2.0.
LAN
Realtek RTL 8102EL
Auto negociação de 10 / 100 Mb/s
Capacidade semi/full-duplex
Suporte
para áudio
de alta
definição
ALC662 / VT1708B
Suporta a especificação High-Definition Audio
Saída de áudio de 5.1 canais
