Motherboard Manual
4
1.5 MOTHERBOARD LAYOUT
KBMS1
ATXPWR2
CPU_FAN1
JUSBV1
VGA1
USB1
RJ45USB1
AUDIO1
LAN
Super
I/O
Codec
FDD1
J_PRINT1
J_ COM 1
PCI1
PCI2
PEX16_ 1
BATTERY
BIOS
SYS_ FAN1
JUSBV 2
PANEL1 JCMOS1
F _U SB2
F_USB1
SATA1 SATA2
SATA3
SATA4
Intel
ICH7
IDE1
ATXPWR1
DDR3_B1
DDR3_A1
Intel
G41
F_AUDIO 1
LGA775
CPU1
Note: ■ represents the 1
st
pin.
