Motherboard Manual
44
JAPANESE
仕様
CPU
LGA 775
Intel Core2Duo / Core2Quad /
Pent iu m Dual-Core / C eleron Du al-Core /
Celeron 4xx processor
(最高のワット: 95W)
Hyper-Thread ing / Execute Disable Bit / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization Technologyをサ
ポートします
FSB
800 / 1066 / 1333 MHz
チップセット
Intel G41
Intel ICH7
メインメモリ
DDR3 DIMMスロット x 2
各DIMMは 256MB / 512MB / 1GB / 2GB
DDR3をサポート
最大メモリ容量4GB
デュアル チャンネルモードDDR3メモリモジュール
DDR3 800/1066/1333(OC)をサポート
登録済みDIMMとECC DIMMはサポートされません
(のCPUのFSBを800 MHzの唯一のDDR3 800をサポートし
ています)
グラフィック
ス
GMA X4500 最大の共有ビデオメモリは256MBです
Super I/O
ITE 8718F
もっとも一般に使用されるレガシーSuper I/O
機能を採用しています。
低ピンカウントインターフェイス
環境コントロールイニシアチブ、
H/Wモニター
ファン速度コントローラ/ モニター
ITEの「スマートガーディアン」機能
IDE
統合IDEコントローラ
Ultra DMA 33 / 66 / 100バスマスタモード
PIO Mode 0~4のサポート、
SATA
統合シリアルATA コントローラ
最高3.0 Gb/秒のデータ転送速度
SATAバージョン2.0仕様に準拠。
LAN
Realtek RTL 8102EL
10 / 100 Mb/秒のオートネゴシエーション
半/全二重機能
HDオーディ
オのサポート
ALC662 / VT1708B
ハイデフィニションオーディオのサポート
5.1 チャンネルオーディオアウト
