GF7050V-M7 SE
9
2. Insert the DIMM vertically and firmly into the slot until the retaining
chip snap back in place and the DIMM is properly seated.
B. Mem ory Capacity
DIMM Socket
Location
DDR2 Module
To t a l Me m o r y
Size
DIMMA1 256MB/512MB/1024MB/2048MB
DIMMA2 256MB/512MB/1024MB/2048MB
Max is 4GB.
