GF7050V-M7 SE
49
仕様
フロッピーコネクタ x1
各コネクタは2つのフロッピードライブをサポートし
ます
IDEコネクタ x1 各コネクタは2つのIDEデバイスをサポートします
プリンタポートコネクタ x1 各コネクタは1つのプリンタポートをサポートします
SA TAコネクタ x4 各コネクタは1つのSATAデバイスをサポートします
フロントパネルコネクタ x1 フロントパネル機能をサポートします
フロントオーディオコネクタ x1 フロントパネルオーディオ機能をサポートします
CDインコネクタ x1 CDオーディオイン機能をサポートします
S/PDIFアウトコネクタ x1 デジタルオーディオアウト機能をサポートします
CPUファンヘッダ x1 CPUファン電源装置(スマートファン機能を搭載)
システムファンヘッダ x1 システムファン電源装置
CMOSクリアヘッダ x1
USBコネクタ x2
各コネクタは2つのフロントパネルUS Bポートをサポ
ートします
電源コネクタ(24ピン) x1
オンボードコ
ネクタ
電源コネクタ(4ピン) x1
背面パネル
I/O
PS/2キーボード x1
PS/2マウス x1
シリアルポート x1
VGAポート x1
LANポート x1
USBポート x4
オーディオジャック x3
ボードサイズ
185 mm (幅) X 244 mm (高さ)
OSサポート Windows XP / VISTA
Biostarは事前のサポートなしにOSサポートを追加ま
たは削除する権利を留保します。
2008/03/12
