GF7050V-M7 SE
3
SPEC
Front Panel Connector x1 Supports front panel facilities
Front Audio Connector x1 Supports front panel audio function
CD-in Connec tor x1 Supports CD audio-in function
S/PDIF out connector x1 Supports digital audio out function
CPU Fan header x1 CPU Fan power supply (with Smart Fan function)
System Fan header x1 System Fan Power supply
Clear CMO S header x1 Res tore CMOS data to factory default
USB connector x2 Each connector supports 2 front panel USB ports
Power Connector (24pin) x1 Connects to Power supply
Power Connector (4pin) x1 Connec ts to Power supply
Back Panel
I/O
PS/2 Keyboard x1
PS/2 Mouse x1
S e ri a l Port x 1
VGA port x1
LAN port x1
USB Port x4
Audio Jack x3
Connects to PS/2 Keyboard
Connects to PS/2 Mouse
Provide RS-232 Serial c onnection
Connects to monitor.
Connects to RJ-45 ethernet cable
Connects to USB devices
Provide Audio-In/Out and microphone connection
Board Size 185 (W) x 244 (L) mm Micro ATX form Fac tor
OS Support Windows XP / VISTA
Biostar Reserves the right to add or remove support
for any OS with or without notice.
1.4 REAR PANEL CONNECT ORS
VGA1
PS/2
Mouse
PS/ 2
Keyboard
COM1 USBX2USBX2
LAN
Lin e In/
Surround
Line Out
Mic In 1/
Bass/ Center
Since t he au dio c hip s up ports Hig h Definiti on A udio Specific atio n, t he func tion of eac h a udi o
jack c an be d efine d b y sof tware. T he in pu t / out put fu nctio n o f each au dio jac k listed ab ove
represe nts t he def ault s etti ng . Ho we ver, wh en c on necti ng e xter nal micr oph on e t o t he au dio
port, pleas e us e t he Lin e I n (Blue) an d M ic In (Pi n k) au dio j ac k.
