Jxx00MH/Jxx00MD/Jxx00ML
25
German
Spezifikationen
CPU-Unterstützung
J1800MH/ J1800MD/ J1800ML: Intel® Celeron® J1800 processor
J1900MH/ J1900MD/ J1900ML: Intel® Celeron® J1900 processor
J2900MH/ J2900MD/ J2900ML: Intel® Pentium® J2900 processor
Festplattenspeicher
Unterstützt zweikanaliges DDR3L 1066/ 1333 (1.35V/1.5V)
2 x DDR3L DIMM-SpeicherSlot, Max. Uterstützung bis zu 16 GB-Speicher
Jedes DIMM unterstützt nicht-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3L-Module
* Bitte konsultieren Sie
www.biostar.com.tw für für Speicherunterstützung Liste.
Arbeitsspeicher
2x SATA 3Gb-Verbindung
Unterstützt Ureinwohner IDE & AHCI Modus
LAN
Jxx00MH/ Jxx00MD: Realtek RTL 8111G
10/ 100/ 1000 Mb Auto-Negotiation, Halb- / Voll-Duplex-fähig
Jxx00ML: Realtek RTL 8106E
10/ 100 Mb Auto-Negotiation, Halb- / Voll-Duplex-fähig
Audio-Codec ALC662, 5.1 Kanäle, HD-Audio
USB
6x USB 2.0-Port (2 hintere I/Os und 4 via interne Header)
1x USB 3.0-Port (1 hintere I/Os)
Erweiterungsanschl
üsse
1x PCIe 2.0 x16-Slot
1x PCIe x1-Slot
Hintere I/Os
1x PS/2-Maus
1x PS/2-Keyboard
1x HDMI-Port (Jxx00MH)
1x DVI-D-Port (Jxx00MD)
1x VGA-Port
1x LAN-Port
1x USB 3.0-Port
2x USB 2.0-Port
3x Audio Jack
Interne I/Os
2x SATA 3.0Gb/s-Verbinung
2x USB 2.0-Header (jeder Header unterstützt 2 USB 2.0-Ports)
1x 4-Pin-Stromverbindung
1x 24-Pin-Stromverbindung
2x System-Ventilatorverbindung
1x Header für Frontpanel
1x Header für Frontaudio
1x Header für klares CMOS
1x Header für Druckerport
1x Serieller Port-Header
Formfaktor Micro-ATX Formfaktor, 190 mm x 188 mm
OS-Unterstützung
Windows 7 / 8 / 8.1
Biostar reserves the right to add or remove support for any OS with or without notice.
