Biostar J1800MH Версия 7.x [28/33] Italian
![Biostar J1800MH Версия 7.x [28/33] Italian](/views2/1710711/page28/bg1c.png)
Motherboard Manual
26
Italian
Specificazioni
Supporto
processore
J1800MH/ J1800MD/ J1800ML: Intel® Celeron® J1800 processor
J1900MH/ J1900MD/ J1900ML: Intel® Celeron® J1900 processor
J2900MH/ J2900MD/ J2900ML: Intel® Pentium® J2900 processor
Memoria
Supporta DDR3L 1066/ 1333 Doppio Canale (1.35V/1.5V)
2 x DDR3L DIMM Slot di Memoria Supporta fino a 16 GB Memoria
Ogni DIMM supporta non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3L moduli
* Si prega di consultare
www.biostar.com.tw per la lista di supporto del memoria.
Memorizzazione
Connettore 2x SATA 3Gb/s
Supporta nativo IDE & AHCI modo
Catena
Jxx00MH/ Jxx00MD: Realtek RTL 8111G
10/ 100/ 1000 Mb auto negoziazione, capacita di duplex Meta / Completo
Jxx00ML: Realtek RTL 8106E
10/ 100 Mb auto negoziazione, capacita di duplex Meta / Completo
Codec Audio
ALC662
Canali Audio di Alta Definizione 5.1
USB
Slot 6x USB 2.0 (2 nei ingressi/ uscite posteriore e 4 da distributori interni)
Slot 1x USB 3.0 (1 nei ingressi/ uscite posteriore)
Slot di espansione
Slot 1x PCIe 2.0 x16
Slot 1x PCIe x1
Ingressi/ Uscite
Posteriore
Mouse 1x PS/2
Tastiera 1x PS/2
Slot 1x HDMI (Jxx00MH)
Slot 1x DVI-D (Jxx00MD)
Slot 1x VGA
Slot 1x LAN
Slot 1x USB 3.0
Slot 2x USB 2.0
Jack audio 3x
Ingressi/ Uscite
Interni
Connettore 2x SATA 3.0Gb/s
Distributore 2x USB 2.0(ogni distributore supporta 2 slot USB 2.0)
Connettore con 4 pin x1
Connettore con 24 pin x1
Connettore Ventilatore Sistema x2
Distributore Pannello Frontale x1
Distributore Audio Frontale x1
Distributore CMOS Diretto x1
Distributore Slot Stampante x1
Distributore Slot Serie x1
Fattore di Forma Fattore di Forma Micro-ATX, 190 mm x 188 mm
Supporto SO
Windows 7 / 8 / 8.1
Biostar si riserva il diritto di aggiungere o ritirare il supporto per qualsiasi SO con o senza
preavviso.
