![Biostar J1800MH Версия 7.x [4/33] Motherboard specifications](/views2/1710711/page4/bg4.png)
Motherboard Manual
2
1.3 Motherboard Specifications
Specifications
CPU Support
J1800MH/ J1800MD/ J1800ML: Intel® Celeron® J1800 processor
J1900MH/ J1900MD/ J1900ML: Intel® Celeron® J1900 processor
J2900MH/ J2900MD/ J2900ML: Intel® Pentium® J2900 processor
Memory
Supports Dual Channel DDR3L 1066/ 1333 (1.35V/1.5V)
2 x DDR3L DIMM Memory Slot, Max. Supports up to 16 GB Memory
Each DIMM supports non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3L module
* Please refer to www.biostar.com.tw for Memory support list.
Storage 2x SATA 3Gb/s Connector, Supports Native IDE, AHCI Mode
LAN
Jxx00MH/ Jxx00MD:
Realtek RTL 8111G, 10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability
Jxx00ML:
Realtek RTL 8106E, 10/ 100 Mb/s auto negotiation, Half / Full duplex capability
Audio Codec ALC662, 5.1 Channels, High Definition Audio
USB
6x USB 2.0 port (2 on rear I/Os and 4 via internal headers)
1x USB 3.0 port (1 on rear I/Os )
Expansion Slots
1x PCIe 2.0 x16 Slot
1x PCIe x1 Slot
Rear I/Os
1x PS/2 Mouse
1x PS/2 Keyboard
1x HDMI Port (Jxx00MH)
1x DVI-D Port (Jxx00MD)
1x VGA Port
1x LAN port
1x USB 3.0 Port
2x USB 2.0 Port
3x Audio Jack
Internal I/Os
2x SATA 3.0Gb/s Connector
2x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1x 4-Pin Power Connector
1x 24-Pin Power Connector
2x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
1x Printer Port Header
1x Serial Port Header
Form Factor Micro-ATX Form Factor, 190 mm x 188 mm
OS Support
Windows 7 / 8 / 8.1
Biostar reserves the right to add or remove support for any OS with or without notice.
