Jxx00MH/Jxx00MD/Jxx00ML
31
Spanish
Especificaciones
Compatibilidad con
el procesador
J1800MH/ J1800MD/ J1800ML: Intel® Celeron® J1800 processor
J1900MH/ J1900MD/ J1900ML: Intel® Celeron® J1900 processor
J2900MH/ J2900MD/ J2900ML: Intel® Pentium® J2900 processor
Memoria
Soporta DDR3L 1066/ 1333 Doble Canal (1.35V/1.5V)
2x DDR3L DIMM Ranura de memoria Soporta hasta 16 GB Memoria
Cada DIMM soporta un modulo non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3L
*Por favor consultar con
www.biostar.com.tw para la lista de compatibilidad con el
memoria.
Almacenamiento
de información
Conector 2x SATA 3Gb/s, Soporta nativo IDE & AHCI modo
LAN
Jxx00MH/ Jxx00MD: Realtek RTL 8111G
10/ 100/ 1000 Mb/s auto negociación, capacidad dúplex Mitad/Completo
Jxx00ML: Realtek RTL 8106E
10/ 100 Mb/s auto negociación, capacidad dúplex Mitad/Completo
Códec Audio ALC662, Canales Audio de Alta Definición 5.1
USB
Ranura 6x USB 2.0 (2 en las entradas/salidas posteriores y 4 por los distribuidores
internos)
Ranura 1x USB 3.0 (1 en las entradas/salidas posteriores)
Ranuras de
Extinción
Ranura 1x PCIe 2.0 x16
Ranura 1x PCIe x1
Panel trasero de
E/S
Ratón 1x PS/2
Teclado 1x PS/2
Ranura 1x HDMI (Jxx00MH)
Ranura 1x DVI-D (Jxx00MD)
Ranura 1x VGA
Ranura 1x LAN
Ranura 1x USB 3.0
Ranura 2x USB 2.0
Socket audio 3x
Conectores en
placa
Conector 2x SATA 3Gb’s
Distribuidor 2x USB 2.0 (cada distribuidor soporta 2 ranuras USB 2.0)
Conector con 4 patillas x1
Conector con 24 patillas x1
Conector Ventilador Sistema x2
Distribuidor Panel Frontal x1
Distribuidor Audio Frontal x1
Distribuidor CMOS Directo x1
Distribuidor Ranura Impresora x1
Distribuidor Ranura Serie x1
Factor de Forma Factor de Forma Micro-ATX, 190 mm x 188 mm
Soporte OS
Windows 7 / 8 / 8.1
Biostar reserva su derecho de añadir o retirar el soporte para cada OS con o sin
notificación.
2014/05/29
