N3700NH/N3150NH/N3050NH
19
Enter the file name and then click
“Save”. Your system information will be
saved to a .txt file.
Open the saved .txt file, you will see
your system information including
motherboard/BIOS/CPU/video/
device/OS information. This
information is also concluded in the
sent mail.
Note1: We will not share customer’s data with any other third parties, so please feel free to provide
your system information while using eHot-Line service.
Note2: If you are not using Outlook Express as your default e-mail client application, you may need
to save the system information to a .txt file and send the file to our tech support with other e-mail
application. Go to the following website http://www.biostar.com.tw/app/en/about/contact.php for
getting our contact information.
