Motherboard Manual
2
1.3 Motherboard Specifications
Specifications
CPU Support
N3700NH: Intel® Pentium® N3700 processor
N3150NH: Intel® Celeron® N3150 processor
N3050NH: Intel® Celeron® N3050 processor
Memory
Supports Dual Channel DDR3L 1600 (1.35V/1.5V)
2x DDR3L SO-DIMM Memory Slot, Max. Supports up to 8 GB Memory
Each DIMM supports non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3L module
* Please refer to www.biostar.com.tw
for Memory support list.
Storage
2x SATA 6Gb/s Connector
Supports AHCI Mode
LAN
Realtek RTL8111H
10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability
Audio Codec ALC662, 5.1 Channels, High Definition Audio
USB
6x USB 2.0 port (2 on rear I/Os and 4 via internal header)
4x USB 3.0 port (2 on rear I/Os and 2 via internal header)
Expansion Slots 1x PCIe 2.0 x1 Slot
Rear I/Os
1x PS/2 Mouse
1x PS/2 Keyboard
1x VGA Port
1x HDMI Port
1x LAN port
2x USB 3.0 Port
2x USB 2.0 Port
3x Audio Jack
Internal I/Os
2x SATA 6.0Gb/s Connector
2x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1x USB 3.0 Header (each header supports 2 USB 3.0 ports)
1x 24-Pin Power Connector
2x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
1x Printer Port Header
1x Serial Port Header
Form Factor Mini-ITX Form Factor, 170 mm x 170 mm
OS Support
Windows 7 (64bit)/ 8.1 (64bit)
Biostar reserves the right to add or remove support for any OS with or without
notice.
