Motherboard Manual
24
French
Spécifications
Support Unité
Centrale
N3700NH: Intel® Pentium® N3700 processor
N3150NH: Intel® Celeron® N3150 processor
N3050NH: Intel® Celeron® N3050 processor
Mémoire
Supporte mémoire DDR3L double canal 1600 (1.35V/1.5V)
Banc de mémoire 2 x DDR3L SO-DIMM, Supporte max. jusqu’à une mémoire
de 8 GB
Chaque module DIMM supporte module DDR3L non-ECC 512MB/ 1/ 2/ 4/ 8 GB
* Veuillez vous reporter à www.biostar.com.tw
pour la liste des soutien de la
mémoire.
Stockage
Connecteur 2 x SATA 6Gb/s
Supporte système indigène AHCI mode
Réseau local
Realtek RTL8111H
10/ 100/ 1000 Mb/s auto négociation, capacité bidirectionnelle à l'alternat /
bidirectionnelle simultanée
Codec audio
ALC662
Canaux 5.1, écoute audio de haute définition
USB
Port 6x USB 2.0 (2 sur les I/O arrières et 4 en interne)
Port 4x USB 3.0 (2 sur les I/O arrières et 2 en interne)
Connecteur
d’extension
1x PCIe 2.0 x1 Fente
I/O arrirèes
1x PS/2 Clavier
1x PS/2 Souris
1x Port HDMI
1x Port VGA
1x port LAN
2x Port USB 3.0
2x Port USB 2.0
3x entrées audio
I/O en interne
2x Connecteur SATA 6.0Gb/s
2x embases USB 2.0 (chaque embase supporte 2 Ports USB 2.0)
1x embases USB 3.0 (chaque embase supporte 2 Ports USB 3.0)
1x 24-Broche de carte
2x Connecteur ventilateur système
1x Fiche panneau avant
1x Fiche audio avant
1x Fiche mémoire CMOS vide
1x Embase port imprimante
1x Embase port série
Facteur
d'encombremen
t
Facteur d'encombrement Mini-ITX, 170 mm x 170 mm
Support SE
Windows 7 (64bit)/ 8.1 (64bit)
Biostar se réserve le droit d’ajouter ou d'enlever le support pour toute SE avec
ou sans préavis.
