N3700NH/N3150NH/N3050NH
23
APPENDIX: SPEC IN OTHER LANGUAGES
Arabic
تﺎﻔﺻاﻮﻤﻟا
ﺔﺠﻟﺎﻌﻤﻟا ةﺪﺣو ةﺪﻋﺎﻗ
ﺔﻳﺰآﺮﻤﻟا
N3700NH: Intel® Pentium® N3700 processor
N3150NH: Intel® Celeron® N3150 processor
N3050NH: Intel® Celeron® N3050 processor
ةﺮآاﺬﻟا
يد ﺔﺟودﺰﻣ ةﺎﻨﻗ ﻢﻋﺪﺗ .يد .را. DDR3L 1600(1.35V/1.5V)
2x يد .يد .را .DDR3L ﺔﺟودﺰﻤﻟا ةﺮآاﺬﻟا تﺎﺤﺘﻓSO-DIMM ﻰﺼﻗأ ﺪﺤآ ﻞﻤﺤﺘﺗ ،8 ﺖﻳﺎﺑﺎﺠﻴﺟ
ةﺮآاذ
دﺰﻣ ﺔﺤﺘﻓ ﻞآ ﺔﺟو DIMM نود ﻞﻤﺤﺘﺗECC 512 ﺖﻳﺎﺑ ﺎﺠﻴﻣ/1/2/4/8 يد ﺖﻳﺎﺑﺎﺠﻴﺟ .يد . را
DDR3L
*ﻊﻗﻮﻤﻟا ﻰﻟإ عﻮﺟﺮﻟا ﻰﺟﺮﻳwww.biostar.com.tw ةﺮآاﺬﻟا ﻢﻋد
ﺔﻤﺋﺎﻘﻟ.
ﻦﻳﺰﺨﺘﻟا
ﺔﻠﺻو 2 x ﺎﺗﺎﺳSATA 6 ﺖﻳﺎﺑ ﺎﺠﻴﺟ /ﺔﻴﻧﺎﺜﻟا
مﻷا ﺪﻳار ﻞﻤﺤﺘﺗAHCI
ﺔﻴﻠﺤﻣ ﺔﻜﺒﺷLAN
Realtek RTL8111H
10 /100 /1000 ﺖﻳﺎﺑﺎﺠﻴﻣ / ﻒﺼﻨﻟا ، ﻲﺋﺎﻘﻠﺗ ﺪﻳﺪﺤﺗ ، ﺔﻴﻧﺎﺜﻟا /ﺔﺟودﺰﻤﻟا ىﻮﺼﻘﻟا ةرﺪﻘﻟا
ﻲﺗﻮﺼﻟا ﺰﻴﻣﺮﺘﻟا
ALC662
5.1 ﺔﻗﺪﻟا ﺔﻴﻟﺎﻋ تاﻮﻨﻗ
مﺎﻋ ﻞﺴﻠﺴﺘﻣ ﻞﻗﺎﻧ
USB
ﺬﻓﺎﻨﻣ6 x مﺎﻋ ﻞﺴﻠﺴﺘﻣ ﻞﻗﺎﻧUSB 2.0 )2 و ﺔﻴﻔﻠﺨﻟا جرﺎﺨﻤﻟاو ﻞﺧاﺪﻤﻟا ﻲﻓ4 عزﻮﻤﻟا لﻼﺧ ﻦﻣ
ﻲﻠﺧاﺪﻟا(
ﺎﻨﻣ ﺬﻓ4 x مﺎﻋ ﻞﺴﻠﺴﺘﻣ ﻞﻗﺎﻧUSB 3.0 )2 و ﺔﻴﻔﻠﺨﻟا جرﺎﺨﻤﻟاو ﻞﺧاﺪﻤﻟا ﻲﻓ2 عزﻮﻤﻟا لﻼﺧ ﻦﻣ
ﻲﻠﺧاﺪﻟا(
ﻊﺳﻮﺘﻟا تﺎﺤﺘﻓ 1 x ﺔﻴﻓﺎﺿﻹا تﺎﻘﺤﻠﻤﻟا ﺬﻔﻨﻣ ﺔﺤﺘﻓPCIe 2.0 x 1
جرﺎﺨﻤﻟاو ﻞﺧاﺪﻤﻟا
ﺔﻴﻔﻠﺨﻟا
1 x PS/2 ةرﺎﻔﻟا
1 x PS/2 ﺮﺗﻮﻴﺒﻤﻜﻠﻟ ﺢﻴﺗﺎﻔﻤﻟا ﺔﺣﻮﻟ
ﺪﻋ ﻞﻴﺻﻮﺗ ﺔﺤﺘﻓ د1 x HDMI حﻮﺿﻮﻟا ﻲﻟﺎﻌﻟا دﺪﻌﺘﻣ ﻂﻴﺳو
دﺪﻋ ﻞﻴﺻﻮﺗ ﺔﺤﺘﻓ1 x ﻲﺋﺮﻤﻟا ضﺮﻌﻟا ﺔﻣﻮﻈﻨﻣVGA
دﺪﻋ ﻞﻴﺻﻮﺘﻟ ﺔﺤﺘﻓ1 x ﺔﻴﻠﺤﻤﻟا ﺔﻜﺒﺸﻟاLAN
دﺪﻋ ﻞﻴﺻﻮﺗ ﺔﺤﺘﻓ2 x مﺎﻋ ﻞﺴﻠﺴﺘﻣ
ﻞﻗﺎﻧUSB 3.0
دﺪﻋ ﻞﻴﺻﻮﺗ ﺔﺤﺘﻓ2 x مﺎﻋ ﻞﺴﻠﺴﺘﻣ ﻞﻗﺎﻧUSB 2.0
دﺪﻋ ﻞﻴﺻﻮﺗ ﺔﺤﺘﻓ3 x تﻮﺼﻠﻟ كﺎﺟ
جرﺎﺨﻤﻟاو ﻞﺧاﺪﻤﻟا
ﺔﻴﻠﺧاﺪﻟا
ﺔﻠﺻو2 x SATA 6 ﺖﻳﺎﺑﺎﺠﻴﺟ /ﺔﻴﻧﺎﺜﻟا
عزﻮﻣ2 x مﺎﻋ ﻞﺴﻠﺴﺘﻣ ﻞﻗﺎﻧUSB 2.0 ) مﺎﻋ ﻞﺴﻠﺴﺘﻣ ﻞﻗﺎﻧ ﻦﻴﺘﺤﺘﻓ ﻞﻤﺤﺘﻳ عزﻮﻣ ﻞآUSB 2.0(
عزﻮﻣ1 x مﺎﻋ ﻞﺴﻠﺴﺘﻣ ﻞﻗﺎﻧUSB 3.0 )ﺎﻋ ﻞﺴﻠﺴﺘﻣ ﻞﻗﺎﻧ ﻦﻴﺘﺤﺘﻓ ﻞﻤﺤﺘﻳ عزﻮﻣ ﻞآ مUSB 3.0(
ﺔﻗﺎﻄﻠﻟ ﺔﻠﺻو1x
24 سﻮﺑد
ﺔﻠﺻو 2 x ﺔﻣﻮﻈﻨﻤﻟا ﺪﻳﺮﺒﺗ حواﺮﻣ
عزﻮﻣ1 x ﺔﻴﻣﺎﻣﻷا ﺔﺣﻮﻠﻟا
عزﻮﻣ1x ﻲﻣﺎﻣﻷا تﻮﺼﻟا
عزﻮﻣ1x ﺮﺷﺎﺒﻣ سﻮﻤﻴﺳ
عزﻮﻣ1x ﺔﻌﺑﺎﻄﻠﻟ ﺔﺤﺘﻓ
عزﻮﻣ1x ﺔﻴﻠﺴﻠﺴﺗ ﺔﺤﺘﻓ
ﻞﻜﺸﻟا ﻞﻣﺎﻋ ﺔﻣﺪﻘﺘﻤﻟا ﺎﻴﺟﻮﻟﻮﻨﻜﺘﻟا دﺪﻣ ﻞﻜﺷ ﻞﻣﺎﻋMini-ITX ،170 ﻢﻣ x 170 ﻢﻣ
ﻞﻴﻐﺸﺘﻟا ﺔﻤﻈﻧأ
ﺔﻣﻮﻋﺪﻤﻟا
ب ﺲآإ زوﺪﻨﻳوWindows 7 (64bit)/ 8.1 (64bit)
رﺎﺘﺳﻮﻴﺑBIOSTAR رﺎﻈﻧأ نوﺪﺑ وأ ﻊﻣ ﻞﻴﻐﺸﺗ مﺎﻈﻧ يﻷ ﻢﻋﺪﻟا ﺔﻟزأ وأ ﺔﻓﺎﺿإ ﻖﺤﺑ ﻆﻔﺘﺤﺗ.
