APPENDIX I: Specicaons in Other Languages | 31
X470NH
German
Spezikaonen
CPU-Unterstützung
Anschluss-AM4 für AMD® A-Serie APU, Ryzen APU / Ryzen CPU
Maximale CPU TDP (Thermal Design Power): 105 Wa
* Bie konsuleren Sie www.biostar.com.tw für CPU-Unterstützungsliste
Chipset AMD® X470
Festplaenspeicher
Unterstützt zweikanaliges DDR4 1866/2133/2400/2667
Unterstützt zweikanaliges DDR4 2933(OC)/3200(OC)/3600(OC)/ 4000(OC)
2 x DDR4 DIMM-SpeicherSlot, Max. Uterstützung bis zu 32 GB-Speicher
Jedes DIMM unterstützt nicht-ECC und ECC Un-gepuert 8/16 GB DDR4-Module
* DDR4 - 2667 nur für Ryzen CPU.
* Bie konsuleren Sie www.biostar.com.tw für für Speicherunterstützung Liste.
Arbeitsspeicher
4x SATA III 6Gb-Verbindung : Unterstützt AHCI & RAID 0,1,10
1x M.2 (M Key) : Unterstützt PCI-E 3.0 x4 (32Gb/s) & SATA III (6Gb/s) SSD
* M.2 : Die Bandbreite ist abhängig von der CPU.
LAN
Realtek RTL8111H
10/ 100/ 1000 Mb Auto-Negoaon, Halb- / Voll-Duplex-fähig
Audio-Codec
ALC887
7.1 Kanäle, HD-Audio
USB
6x USB 3.1 Gen1 (5Gb/s)-Port (4 hintere I/Os und 2 via interne Header)
4x USB 2.0-Port (2 hintere I/Os und 2 via interne Header)
Erweiterungsanschlüsse 1x PCIe 3.0 x16-Slot (Die Bandbreite ist abhängig von der CPU)
Hintere I/Os
1x PS/2-Keyboard / Maus
1x HDMI-Port
1x VGA-Port
1x LAN-Port
4x USB 3.1 Gen1 (5Gb/s)-Port
2x USB 2.0-Port
3x Audio Jack
Interne I/Os
4x SATA III 6.0Gb/s-Verbinung
1x USB 2.0-Header (jeder Header unterstützt 2 USB 2.0-Ports)
1x USB 3.1 Gen1 (5Gb/s)-Header (jeder Header unterstützt 2 USB 3.1 Gen1-Ports)
1x 4-Pin-Stromverbindung
1x 24-Pin-Stromverbindung
1x CPU-Venlatorverbindung
1x System-Venlatorverbindung
1x Header für Frontpanel
1x Header für Frontaudio
1x Header für klares CMOS
1x Header für Redner
1x Serieller Port-Header
1x S/PDIF-Auswurfsverbindung
Formfaktor Mini-ITX Formfaktor, 170 mm x 170 mm
OS-Unterstützung
Windows 7(64bit) / 10(64bit)
Biostar reserves the right to add or remove support for any OS with or without noce
