Biostar B450NH Версия 6.0 [12/33] Sata configuration
![Biostar B450NH Версия 6.0 [12/33] Sata configuration](/views2/1710928/page12/bgc.png)
12 | 2. Advanced Menu
PS2 Keyboard PowerOn
This item allows you to control the keyboard power on funcon.
Opons: Disabled (Default) / Any Key / Stroke Key / Specic Key
Stroke Keys
This item will show only when Keyboard PowerOn is set “Stroke Key.”
Opons: Wake Key (Default) / Power Key / Ctrl+F1 / Ctrl+F2 / Ctrl+F3 / Ctrl +F4 / Ctrl+F5 / Ctrl+F6
Specic Key
This item will show only when Keyboard PowerOn is set “Specic Key.” Press Enter to set Specic
key.
PS2 Mouse PowerOn
This item allows you to control the mouse power on funcon.
Opons: Disabled (Default) / Enabled
SATA Configuration
OnChip SATA funcon
This item enables or disables OnChip SATA funcon.
Opons: Enabled (Default) / Disabled
OnChip SATA Type
This item select OnChip SATA Type.
Opons: AHCI (Default) / RAID
Note
»
The following items appear only when you set the OnChip SATA Type funcon to [RAID]
NVMe RAID mode
This item enables or disables NVMe RAID mode.
Opons: Disabled (Default) / Enabled
