Biostar TA70U3-LSP Версия 6.x [11/42] B memory capacity

TA70U3-LSP

B. Memory Capacity

DIMM Socket Location

DDR3 Module

Total Memory Size

DDR3_A1 512MB/1GB/2GB/4GB/8GB/16GB

Max is 32GB.

DDR3_B1 512MB/1GB/2GB/4GB/8GB/16GB

C. Dual Channel Memory Installation

Please refer to the following requirements to activate Dual Channel function:

Install memory module of the same density in pairs, shown in the table.

Dual Channel Status DDR3_A1 DDR3_B1

Disabled O X

Disabled X O

Enabled O O

(O means memory installed, X means memory not installed.)

Note: When installing more than one memory module, we recommend to use the same

brand and capacity memory on this motherboard.
