Motherboard Manual
2
1.3 Motherboard Specifications
Specifications
CPU Support
Socket FM2+ supports AMD FM2+/FM2 A-series APU
Maximum CPU TDP (Thermal Design Power): 100Watt
* Please refer to www.biostar.com.tw
for CPU support list.
Chipset AMD A70M
Memory
Supports Dual Channel DDR3 800/ 1066/ 1333/ 1600/ 1866/ 2133/ 2400(OC)/
2600(OC)
2 x DDR3 DIMM Memory Slot, Max. Supports up to 32 GB Memory
Each DIMM supports non-ECC 512MB/ 1/ 2/ 4/ 8/ 16 GB DDR3 module
* Please refer to www.biostar.com.tw
for Memory support list.
Storage Supports RAID 0,1 & AHCI
LAN
Realtek RTL 8111G
10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability
Audio Codec
ALC662
5.1 Channels, High Definition Audio
USB
8x USB 2.0 port (4 on rear I/Os and 4 via internal headers)
4x USB 3.0 port (2 on rear I/Os and 2 via internal header)
Expansion Slots
3x PCI Slot
2x PCIe 2.0 x1 Slot
1x PCIe 3.0 x16 Slot (Only FM2+ processors can support PCIe 3.0.)
Rear I/Os
1x PS/2 Mouse/Keyboard
1x VGA Port
1x DVI Port
1x LAN port
4x USB 2.0 Port
2x USB 3.0 Port
3x Audio Jack
Internal I/Os
6x SATA 6.0Gb/s Connector
2x USB 2.0 Header
1x USB 3.0 Header
1x 4-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
2x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
1x Printer Port Header
1x Consumer IR Header
1x Serial Port Header
1x S/PDIF out Connector
Form Factor ATX Form Factor, 295 mm x 200 mm
OS Support
Windows XP / 7 / 8 / 8.1
Biostar reserves the right to add or remove support for any OS with or without notice.
