TA770E3/ TA770XE3/TA790XE3 BIOS Manual
21
5 Chipset Menu
This submenu allows you to configure the speci fic features of the chipset installed on
your system. This chipset manage bus speeds and access to system memory
resources, such as DRAM. It also coordinates communications with the PCI bus.
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Chipset T-Series
vxx.xx (C)Copyright 1985-200x, Amer ican Megatre nds, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
Options for SBAdvanced Chipset Settings
> NorthBridge Configuration
> OnBoard Peripherals Configur ation
> SouthBridge Configuration
Exit
SouthBridge Co nfig uration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, Amer ican Megatre nds, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
OHCI HC(Bus 0 Dev 18 Fn 0) [ Enabled]
OHCI HC(Bus 0 Dev 18 Fn 1) [ Enabled]
EHCI HC(Bus 0 Dev 18 Fn 2) [ Enabled]
OHCI HC(Bus 0 Dev 19 Fn 0) [ Enabled]
OHCI HC(Bus 0 Dev 19 Fn 1) [ Enabled]
EHCI HC(Bus 0 Dev 19 Fn 2) [ Enabled]
OHCI HC(Bus 0 Dev 20 Fn 5) [ Enabled]
OnChip SATA Channel [ Enabled]
OnChip SATA Type [ Native IDE]
SATA IDE Combined Mode [ Enabled]
Power Saving Features [ Disabled]
SouthBridge Chipset Configurat ion
SB750 CIMx Version : 4.4.0
> SB Azalia Audio Configuratio n
Options
for SB HD Azalia
