TA770E3/ TA770XE3/TA790XE3 BIOS Manual
30
Memory Over Voltage
This item allows you to select DDR Over Voltage Control.
Options: 1.600V (Default) / 1.620V ~ 2.600V (Interval: 0.02V)
Chipset Over Voltage
This item allows you to select chipset Voltage Control.
Options: Auto (Default) / 1.160V ~ 2.340V (Interval: 0.02V)
CPU NB Voltage
This item allows you to select CPU NB Over Voltage Control.
Options: StartUp (Default) / +0.10V / +0.20V / +0.30V
HT Over Voltage
This item allows you to select HT Over Voltage Control.
Options: StartUp (Default) / 0.100V ~ 0.700V (Interval: 0.100V)
CPU Frequency
This item allows BIOS to select CPU Over Clock.
Options: 200MHz (Default) / 200MHz~600MHz
Spread Spectrum
This item allows you to control Spread Spectrum function.
Options: Disabled (Default) / Enabled
