TA770E3/ TA770XE3/TA790XE3 BIOS Manual

Option ROM POST Delay

Options: Disabled (Default) / 1 ~ 7 Seconds

SATA IDE Combined Mode

This option controls the SATA/PATA combined mode.

Options: Enabled (Default) / Disabled

Power Saving Features

Disable / Enable power saving features in SB. Generally, this feature should be

disabled for desktop and enabled for mobile.

Options: Disabled (Default) / Enabled

NorthBridge Configuration

BIOS SETUP UTILITY

Chipset

Select Screen

Select Item

Go to Sub Screen

General Help

Save and Exit

Exit

Enter

F10

ESC

NorthBridge Configuration

Primary Video Controller [PCIE GFX0-GFX2-GPP]

> PCI Express Configuration
