TA770E3/ TA770XE3/TA790XE3 BIOS Manual
37
ECC Configuration
BIOS SETUP UTILITY
vxx.xx (C)Copyright 1985-200x, American Me gatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
ECC Configuration
ECC Mode [Dis abled]
DRAM ECC Enable [Dis abled]
DRAM SCRUB REDIRECT [Dis abled]
4-Bit ECC Mode [Dis abled]
DRAM BG Scrub [Dis abled]
Data Cache BG Scrub [Dis abled]
L2 Cache BG Scrub [Dis abled]
L3 Cache BG Scrub [Dis abled]
Set the level of ECC
protection. Note: The
Super ECC mode
dynamically sets the
DRAM scrub rate so
all of memory is
scrubbed in 8 hours.
T-Series
ECC Mode
This item allows you to select the DRAM ECC Mode.
Options: Disabled (Default) / Basic / Good / Super / Max / User
DRAM ECC Enabled
Options: Disabled (Default) / Enabled
DRAM Scrub Redirect
Options: Disabled (Default) / Enabled
4-bit ECC Mode
Options: Disabled (Default) / Enabled
DRAM BG Scrub/Data Cache BG Scrub/L2 Cache BG Scrub/L3 Cache BG Scrub
Options: Disabled (Default) / 40ns / 80ns / 160ns / 320ns / 640ns / 1.28us / 2.56us /
5.12us / 10.2us / 20.5us / 41.0us / 81.9us / 163.8us / 327.7us / 655.4us
Содержание
- Ta770e3 ta770xe3 ta790xe3 bios manual 1
- Acpi support 2
- Apm support 2
- Bios setup 2
- Epa green pc support 2
- Introduction 2
- Plug and play support 2
- Ta770e3 ta770xe3 ta790xe3 bios manual 2
- Dram support 3
- Notice 3
- Pci bus support 3
- Supported cpus 3
- Ta770e3 ta770xe3 ta790xe3 bios manual 3
- Using setup 3
- Ami bios 4
- Main menu 4
- Once you enter ami bios setup utility the main menu will appear on the screen providing an overview of the basic system information 4
- Set the system date note that the day automatically changes when you set the date 4
- Set the system internal clock 4
- Shows system information including bios version and built date 4
- Shows system memory size 4
- System date 4
- System memory 4
- System time 4
- Ta770e3 ta770xe3 ta790xe3 bios manual 4
- Floppy a 5
- Ide configuration 5
- Select the type of floppy disk drive installed in your system options 360k 5 5 in 1 m 5 5 in 720k 3 in 1 4m 3 in 2 8m 3 in disabled 5
- Ta770e3 ta770xe3 ta790xe3 bios manual 5
- To enter the sub menu of detailed options 5
- Ta770e3 ta770xe3 ta790xe3 bios manual 6
- Ta770e3 ta770xe3 ta790xe3 bios manual 7
- Advanced menu 8
- Beware of that setting inappropriate values in items of this menu may cause system to malfunction 8
- Cpu configuration 8
- Notice 8
- Ta770e3 ta770xe3 ta790xe3 bios manual 8
- The advanced menu allows you to configure the settings of cpu super i o power management and other system devices 8
- This item shows the cpu information that the bios automatically detects 8
- Ta770e3 ta770xe3 ta790xe3 bios manual 9
- Superio configuration 10
- Ta770e3 ta770xe3 ta790xe3 bios manual 10
- Choose this item and then the bios will auto test and detect the cpu system fan functions and show cpu system fan speed 11
- Cpu smart fan 11
- Mouse poweron 11
- Restore on ac power loss 11
- Smart fan calibration 11
- Smart fan configuration 11
- Ta770e3 ta770xe3 ta790xe3 bios manual 11
- This item allows you to control the cpu smart fan function options disabled default auto 4pin 3pin 11
- This item allows you to control the mouse power on function options disabled default enabled 11
- This setting specifies how your system should behave after a power fail or interrupts occurs choosing disabled will leave the computer in the power off state choosing enabled will restore the system to the status before power failure or interrupt occurs options power off default power on last state 11
- Hardware health configuration 12
- Ta770e3 ta770xe3 ta790xe3 bios manual 12
- Power configuration 13
- Ta770e3 ta770xe3 ta790xe3 bios manual 13
- Ta770e3 ta770xe3 ta790xe3 bios manual 14
- Ta770e3 ta770xe3 ta790xe3 bios manual 15
- Usb configuration 15
- Bios ehci hand off 16
- Ta770e3 ta770xe3 ta790xe3 bios manual 16
- This item allows you to enable support for operating systems without an ehci hand off feature options enabled default disabled 16
- Usb mass storage dev ice configuration 16
- Usb mass storage reset delay this item allows you to set the reset delay for usb mass storage device options 20 sec default 10 sec 30 sec 40 sec emulation type this item allows you to select the emulation type of the usb mass storage device options auto default floppy forced fdd hard disk cdrom 16
- Beware of that setting inappropriate values in items of this menu may cause system to malfunction 17
- Clear nvram 17
- Notice 17
- Pcipnp menu 17
- Plug play os 17
- Ta770e3 ta770xe3 ta790xe3 bios manual 17
- This item allows you to clear the data in the nvram cmos by selecting yes options no default yes 17
- This section describes configuring the pci bus system pci or personal computer interconnect is a system which allows i o devices to operate at speeds nearing the speed of the cpu itself uses when communicating with its own special components 17
- When set to yes bios will only initialize the pnp cards used for the boot sequence vga ide scsi the rest of the cards will be initialized by the pnp operating system like window 95 when set to no bios will initialize all the pnp cards for non pnp operating systems dos netware this option must set to no options no default yes 17
- Allocate irq to pci vga 18
- Palette snooping 18
- Pci ide busmaster 18
- Pci latency timer 18
- Pci resource 18
- Some old graphic controllers need to snoop on the vga palette and then map it to their display as a way to provide boot information and vga compatibility this item allows such snooping to take place options disabled default enabled 18
- Ta770e3 ta770xe3 ta790xe3 bios manual 18
- This item allows bios to choose a irq to assign for the pci vga card options yes default no 18
- This item controls how long a pci device can hold the pci bus before another takes over the longer the latency the longer the pci device can retain control of the bus before handing it over to another pci device options 64 default 0 255 18
- This item is a toggle for the built in driver that allows the onboard ide controller to perform dma direct memory access transfers options enabled default disabled 18
- Pci express configuration 19
- Ta770e3 ta770xe3 ta790xe3 bios manual 19
- Boot device priority 20
- Boot menu 20
- Hard disk drives 20
- Items in this sub menu specify the boot device priority sequence from the available devices the number of device items that appears on the screen depends on the number of devices installed in the system options removable hard disk cdrom legacy lan disabled 20
- Removable drives 20
- Ta770e3 ta770xe3 ta790xe3 bios manual 20
- The bios will attempt to arrange the hard disk boot sequence automatically you can also change the booting sequence the number of device items that appears on the screen depends on the number of devices installed in the system options pri master pri slave sec master sec slave usb hdd0 usb hdd1 usb hdd2 bootable add in cards 20
- The bios will attempt to arrange the removable drive boot sequence automatically you can also change the booting sequence the number of device items that appears on the screen depends on the number of devices installed in the system options floppy disks zip100 usb fdd0 usb fdd1 usb zip0 usb zip1 ls120 20
- This menu allows you to setup the system boot options 20
- Addon rom display mode 21
- Boot success beep 21
- Bootup num lock 21
- Cd dvd drives 21
- Full screen logo show 21
- Ignore memory error messages 21
- Interrupt 19 capture 21
- Quick boot 21
- Ta770e3 ta770xe3 ta790xe3 bios manual 21
- Chipset menu 22
- Southbridge configuration 22
- Ta770e3 ta770xe3 ta790xe3 bios manual 22
- This submenu allows you to configure the specific features of the chipset installed on your system this chipset manage bus speeds and access to system memory resources such as dram it also coordinates communications with the pci bus 22
- Ta770e3 ta770xe3 ta790xe3 bios manual 23
- Northbridge configuration 24
- Ta770e3 ta770xe3 ta790xe3 bios manual 24
- Gen2 high speed mode options auto default disabled software initiated advertised rc 25
- Pci express configuration 25
- Peer to peer among gfx gfx2 options disabled default enabled gpp slots power limit w options 25 default 0 255 port 02 04 05 07 features 25
- Ta770e3 ta770xe3 ta790xe3 bios manual 25
- Ta770e3 ta770xe3 ta790xe3 bios manual 26
- Mac id information 27
- Onboard peripherals configuration 27
- Realtek option rom 27
- Realtek pcie nic 27
- Ta770e3 ta770xe3 ta790xe3 bios manual 27
- This area shows the mac id 27
- This item allows you to enable or disable the onboard lan boot rom this option needs to be enabled for pxe boot support options disabled default enabled 27
- This option allows you to control the onboard lan controller options enable default disable 27
- Beware of that setting inappropriate values in items of this menu may cause system to malfunction 28
- Notice 28
- Overclock navigator 28
- Overclock navigator is designed for beginners in overclock field based on many test and experiments from biostar engineer team overclock navigator provides 3 default overclock configurations that are able to raise the system performance options normal default automate overclock manual overclock 28
- T series menu 28
- Ta770e3 ta770xe3 ta790xe3 bios manual 28
- This submenu allows you to change voltage and clock of various devices however we suggest you use the default setting changing the voltage and clock improperly may damage the device 28
- Auto overclock system 29
- Cautions 29
- Not every amd cpu performs the above overclock setting ideally the difference may vary with the installed cpu model 29
- Ta770e3 ta770xe3 ta790xe3 bios manual 29
- The overclock navigator provides 3 different engines helping you to overclock your system these engines will boost your system performance to different level options 29
- V12 tech engine this engine will make a best over clock performance 29
- V6 tech engine this engine will make a good over clock performance 29
- V8 tech engine this engine will make a better over clock performance 29
- Cpu ov er voltage 30
- Manual overclock system m o s 30
- Mos is designed for experienced overclock users it allows users to customize personal overclock setting 30
- Over voltage configuration 30
- Ta770e3 ta770xe3 ta790xe3 bios manual 30
- This item allows you to select cpu over voltage control options auto default 0 20v 1 60v interval 0 2v 30
- Cpu frequency 31
- Spread spectrum 31
- Ta770e3 ta770xe3 ta790xe3 bios manual 31
- Core did 32
- Core fid 32
- Core vid 32
- Cpu fid vid control 32
- Custom p states 32
- Nb vid 32
- Options divided by 1 default divided by 2 divided by 4 divided by 8 divided by 16 32
- Set the voltage to use for nb pstate selected value is saved in the _pss object options 1 000v default 0 125v 1 500v 32
- Ta770e3 ta770xe3 ta790xe3 bios manual 32
- This function allows you to adjust the voltage of cpu options 0 125v 1 500v differed by cpu 32
- This item allows you to select the p states controlling options disabled default enabled 32
- This item allows you to select the ratio frequency of am2 cpu options x8 1600mhz x15 3100mhz differed by cpu 32
- Biostar memory insight 33
- Dram timing configuration 33
- Nb fid 33
- Ta770e3 ta770xe3 ta790xe3 bios manual 33
- This item allows you to select the frequency of nb chip options 2000mhz default 800mhz 7000mhz 33
- Ta770e3 ta770xe3 ta790xe3 bios manual 34
- Hyper transport configuration 35
- Ta770e3 ta770xe3 ta790xe3 bios manual 35
- Memory configuration 36
- Ta770e3 ta770xe3 ta790xe3 bios manual 36
- Ta770e3 ta770xe3 ta790xe3 bios manual 37
- Ecc configuration 38
- Ecc mode this item allows you to select the dram ecc mode options disabled default basic good super max user dram ecc enabled options disabled default enabled dram scrub redirect options disabled default enabled 4 bit ecc mode options disabled default enabled dram bg scrub data cache bg scrub l2 cache bg scrub l3 cache bg scrub options disabled default 40ns 80ns 160ns 320ns 640ns 1 8us 2 6us 5 2us 10 us 20 us 41 us 81 us 163 us 327 us 655 us 38
- Ta770e3 ta770xe3 ta790xe3 bios manual 38
- G p u phase control 39
- G p u phase mode 39
- Ta770e3 ta770xe3 ta790xe3 bios manual 39
- This item allows you to control g p u phase mode power saving technology options auto default off 39
- Integrated memory test 40
- Integrated memory test allows users to test memory module compatibilities without additional device or software 40
- Step 1 40
- Step 2 40
- Ta770e3 ta770xe3 ta790xe3 bios manual 40
- This item is disabled on default change it to enable to precede memory test 40
- When the process is done change the setting back from enabled to disabled to complete the test 40
- Abandon all changes made during the current session and exit setup 41
- Abandon all changes made during the current session and restore the previously saved values 41
- Discard changes 41
- Discard changes and exit 41
- Exit menu 41
- Load optimal defaults 41
- Save all configuration changes to cmos ram and exit setup 41
- Save changes and exit 41
- Ta770e3 ta770xe3 ta790xe3 bios manual 41
- This menu allows you to load the optimal default settings and save or discard the changes to the bios items 41
- This selection allows you to reload the bios when problem occurs during system booting sequence these configurations are factory settings optimized for this system 41
- Cmos backup function 42
- It allows users to save different cmos settings into bios rom and reload any saved cmos setting for customizing system configurations moreover users are able to save an ideal overclock setting during overclock operation there are 10 sets of record addresses in total and users are able to name the cmos data according to personal preference 42
- Security 42
- Ta770e3 ta770xe3 ta790xe3 bios manual 42
