A780GE/A760GE/A785GE
31
A780GE/A760GE A785GE
LAN
Realtek RTL 8111DL
10 / 100 / 1000 Mb/s Auto-Negotiation
Halb-/ Vollduplex-Funktion
Realtek RTL 8111DL
10 / 100 / 1000 Mb/s Auto-Negotiation
Halb-/ Vollduplex-Funktion
HD
Audio-Unters
tützung
ALC662
5.1-Kanal-Audioausgabe
Unterstützt High-Definition Audio
ALC662
5.1-Kanal-Audioausgabe
Unterstützt High-Definition Audio
PCI Express Gen2 x16 Steckplatz x1 PCI Express Gen2 x16 Steckplatz x1
Steckp lätze
PCI-Steckplatz x2 PCI-Steckplatz x2
Diskettenlaufwerkanschluss x1 Diskettenlaufwerkanschluss x1
IDE-Anschluss x1 IDE-Anschluss x1
SATA-Anschluss x4 SATA-Anschluss x4
Fronttafelanschluss x1 Fronttafelanschluss x1
Front-Audioanschluss x1 Front-Audioanschluss x1
S/PDIF- Ausgangsanschluss x1 S/PDIF- Ausgangsanschluss x1
CPU-Lüfter-Sockel x1 CPU-Lüfter-Sockel x1
System-Lüfter-Sockel x1 System-Lüfter-Sockel x1
"CMOS löschen "-Sockel x1 "CMOS löschen "-Sockel x1
USB-Anschluss x2 USB-Anschluss x2
Stromanschluss (24-polig) x1 Stromanschluss (24-polig) x1
Stromans chluss (4-polig) x1 Stromansch luss (4-polig ) x1
Druckeranschluss Anschluss x1 Druckeranschluss Anschluss x1
Onboard-Ans
chluss
Serieller Anschluss x1 Serieller Anschluss x1
Rückseiten-E
/A
PS/2-Tastatur x1
PS/2- Maus x1
VGA-Anschluss x1
LAN-Anschluss x1
USB-Anschluss x4
Audioanschluss x3
DVI-Anschluss x1
PS/2-Tastatur x1
PS/2- Maus x1
VGA-Anschluss x1
LAN-Anschluss x1
USB-Anschluss x4
Audioanschluss x3
DVI-Anschluss x1
Platinengröß
e
200 mm (B) X 244 mm (L) 200 mm (B) X 244 mm (L)
Sonderfunkti
onen
Unterstützt RAID 0 / 1 / 1+0 Unterstützt RAID 0 / 1 / 1+0
OS-Unterstü
tzung
Windows XP / Vista 32 / 64
Biostar behält sich das Recht vor, ohne
Ankündigung die Unterstützung für ein
Betriebssystem hinzuzufügen oder zu
entfernen.
Windows XP / Vista 32 / 64
Biostar behält sich das Recht vor, ohne
Ankündigung die Unterstützung für ein
Betriebssystem hinzuzufügen oder zu
entfernen.
