A780GE/A760GE/A785GE
39
A780GE/A760GE A785GE
LAN
Realtek RTL 8111DL
Auto negociação de 10 / 100 / 1000 Mb/s
Capacidade semi/full-duplex
Realtek RTL 8111DL
Auto negociação de 10 / 100 / 1000 Mb/s
Capacidade semi/full-duplex
Suporte
para áudio
de alta
definição
ALC662
Saída de áudio de 5.1 canais
Suporta a especificação High-Definition Audio
ALC662
Saída de áudio de 5.1 canais
Suporta a especificação High-Definition Audio
Ranhura PCI Express Gen2 x16 x1 Ranhura PCI Express Gen2 x16 x1
Ranhuras
Ranhura PCI x2 Ranhura PCI x2
Conector da unidade de disquetes x1 Conector da unidade de disquetes x1
Conector IDE x1 Conector IDE x1
Conector SATA x4 Conector SATA x4
Conector do painel frontal x1 Conector do painel frontal x1
Conector de áudio frontal x1 Conector de áudio frontal x1
Conector de saída S/PDIF x1 Conector de saída S/PDIF x1
Conector da ventoinha da CPU x1 Conector da ventoinha da CPU x1
Conector da ventoinha do sistema x1 Conector da ventoinha do sistema x1
Conector para limpeza do CMOS x1 Conector para limpeza do CMOS x1
Conector USB x2 Conector USB x2
Conector de alimentação x1
(24 pinos)
Conector de alimentação x1
(24 pinos)
Conector de alimentação x1
(4 p inos)
Conector de alimentação x1
(4 p inos)
Conector da para impressora x1 Conector da para impressora x1
Conectores
na placa
Conector da Porta série x1 Conector da Porta série x1
Entradas/S
aídas no
painel
traseiro
Tec lado PS /2 x 1
Rato PS/2 x1
Porta VGA x1
Porta LAN x1
Porta USB x4
Tomada de áudio x3
Porta DVI x1
Tec lado PS /2 x 1
Rato PS/2 x1
Porta VGA x1
Porta LAN x1
Porta USB x4
Tomada de áudio x3
Porta DVI x1
Tamanho
da placa
200 mm (L) X 244 mm (A) 200 mm (L) X 244 mm (A)
Característi
cas
especiais
Suporta as funções RAID 0 / 1 / 1+0 Suporta as funções RAID 0 / 1 / 1+0
Sistemas
operativos
suportados
Windows XP / Vista 32 / 64
A Biostar reserva-se o direito de adicionar ou
remover suporte para qualquer sistema
operativo com ou sem aviso prévio.
Windows XP / Vista 32 / 64
A Biostar reserva-se o direito de adicionar ou
remover suporte para qualquer sistema
operativo com ou sem aviso prévio.
