A780GE/A760GE/A785GE
41
A780GE/A760GE A785GE
Obsługa
audio HD
ALC662
5.1 kanałowe wyjście audio
Obsługa High-Def in ition Audio
ALC662
5.1 kanałowe wyjście audio
Obsługa High-Def in ition Audio
Gniazdo PCI Express Gen2 x16 x1 Gniazdo PCI Express Gen2 x16 x1
Gniazda
Gniazdo PCI x2 Gniazdo PCI x2
Złącze napędu dyskietek x1 Złącze napędu dyskietek x1
Złącze IDE x1 Złącze IDE x1
Złącze SATA x4 Złącze SATA x4
Złącze panela przedniego x1 Złącze panela przedniego x1
Przednie złącze audio x1 Przednie złącze audio x1
Złącze wyjścia S/PDIF x1 Złącze wyjścia S/PDIF x1
Złącze główkowe wentylatora procesora x1 Złącze główkowe wentylatora procesora x1
Złącze główkowe wentylatora systemowego x1 Złącze główkowe wentylatora systemowego x1
Złącze główkowe kasowania CMOS x1 Złącze główkowe kasowania CMOS x1
Złącze USB x2 Złącze USB x2
Złącze zasilania (24 pinowe) x1 Złącze zasilania (24 pinowe) x1
Złącze zasilania (4 p inowe) x1 Złącze zasilania (4 pino we) x1
Złącze Port drukarki x1 Złącze Port drukarki x1
Złącza
wbudowan
e
Złącze Port szeregowy x1 Złącze Port szeregowy x1
Back Panel
I/O
Klawiatura PS/2 x1
Mysz PS /2 x1
Port VGA x1
Port LAN x1
Port USB x4
Gniazdo audio x3
Port DVI x1
Klawiatura PS/2 x1
Mysz PS /2 x1
Port VGA x1
Port LAN x1
Port USB x4
Gniazdo audio x3
Port DVI x1
Wymiary
płyty
200 mm (S) X 244 mm (W) 200 mm (S) X 244 mm (W)
Funkcje
specjalne
Obsługa RAID 0 / 1 / 1+0 Obsługa RAID 0 / 1 / 1+0
Obsluga
systemu
operacyjne
go
Windows XP / Vista 32 / 64
Biostar zastrzega sobie prawo dodawania lub
odwoływania obsług i dowo ln ego systemu
operacyjnego b ez powiado mienia.
Windows XP / Vista 32 / 64
Biostar zastrzega sobie prawo dodawania lub
odwoływania obsług i dowo ln ego systemu
operacyjnego b ez powiado mienia.
