![Biostar A780GE Версия 6.x [34/49] Motherboard manual](/views2/1711555/page34/bg22.png)
Motherboard Manual
32
FRENCH
A780GE/A760GE A785GE
UC
Socket AM2+
Processeurs AMD Sempron / Athlon / Athlon II /
Phenom / Ph enom II
L'architecture AMD 64 permet le calcul 32 et 64
bits
Prend en charge Hyper Transport 3.0 et
Cool’n’Quiet
(Watt maximum : 95W )
Socket AM2+
Processeurs AMD Sempron / Athlon / Athlon II /
Phenom / Ph enom II
L'architecture AMD 64 permet le calcul 32 et 64
bits
Prend en charge Hyper Transport 3.0 et
Cool’n’Quiet
(Watt maximum : 95W )
Bus frontal
Prend en charge Hyper Transport 3.0 jusqu'à
une bande passante de 5.2 GT/s
Prend en charge Hyper Transport 3.0 jusqu'à
une bande passante de 4.4 GT/s
Chipset
AMD 780G / 760G
AMD SB710
AMD 785G
AMD SB710
Super E/S
ITE 8718F
Fournit la fonctionnalité de Super E/S
patrimoniales la plus utilisée.
Interface à f aib le co mpte de b roches
Initiatives de contrôle environnementales,
Moniteur d e mat ériel
Fonction "Gardien intelligent" de l'ITE
ITE 8718F
Fournit la fonctionnalité de Super E/S
patrimoniales la plus utilisée.
Interface à f aib le co mpte de b roches
Initiatives de contrôle environnementales,
Moniteur d e mat ériel
Fonction "Gardien intelligent" de l'ITE
Mémoire
principale
Fentes DDR2 DIMM x 2
Capacité mémo ire max imale de 8 Go
Chaque DIMM prend en charge des DDR2 de
256 Mo/512 Mo et 1Go/2Go/4Go
Module de mémoire DDR2 à mode à double voie
Prend en charge la DDR2 533 / 667 / 800
Prend en charge la DDR2 1066 (for AM2+/AM3
CPU only)
Les DIMM à registres et DIMM avec code
correcteurs d'erreurs ne sont pas prises en
charge
Fentes DDR2 DIMM x 2
Capacité mémo ire max imale de 8 Go
Chaque DIMM prend en charge des DDR2 de
256 Mo/512 Mo et 1Go/2Go/4Go
Module de mémoire DDR2 à mode à double voie
Prend en charge la DDR2 533 / 667 / 800
Prend en charge la DDR2 1066 (for AM2+/AM3
CPU only)
Les DIMM à registres et DIMM avec code
correcteurs d'erreurs ne sont pas prises en
charge
Graphiques
Integré dans la chipset AMD 780G / 760G
Mémoire vidéo partagée maximale de 512 Mo
Prise en charge DX10/HDCP (780G ONLY)
Integré dans la chipset AMD 785G
Mémoire vidéo partagée maximale de 512 Mo
Prise en charge HDCP
IDE
Contrôleur IDE intégré
Mode principale de Bus Ultra DMA 33 / 66 / 100
/ 133
Prend en charge le mode PIO 0~4,
Contrôleur IDE intégré
Mode principale de Bus Ultra DMA 33 / 66 / 100
/ 133
Prend en charge le mode PIO 0~4,
SATA
Contrôleur Serial ATA
int égré
Taux de transfert jusqu'à 3 Go/s.
Conforme à la spéc ificat ion SATA Vers ion 2.0
Contrôleur Serial ATA
int égré
Taux de transfert jusqu'à 3 Go/s.
Conforme à la spéc ificat ion SATA Vers ion 2.0
