GF8100 M2G+ BIOS Manual
24
5 Chipset Menu
T his submenu allows you to configure the speci fic featur es of the chipset installed on
your system. This chipset manage bus speeds and access to system memory
resources, such as DRAM. It also coordinates communications with the PCI bus.
Notice
z Beware of that setting inappropriate values in items of this menu may cause
system to malfunction.
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Chipset Performance
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Advanced Chipset Settings
WARNING: Setting wrong values in below sections
may cause system to malfunction.
Primary Graphics Adapter [PCIE VGA Card Firs]
iGPU and Ext-VGA Selection [Disable iGPU if Ex]
iGPU Frame Buffer Detect [Auto]
PCIE training [Gen2 if supported]
Iso Flow Control [Disabled]
Hi Priority Channel [Enabled]
Display Refresh [Enabled]
Hybrid SLI support [Disabled]
iGPU Frame Buffer Size [256MB]
Exit
1 Memory have to
over 2G size
2 Primary Graphics
Adapter decide
by Hybrid-Mode
3 External VGA
must support this
feature
Hybrid SLI Support
This item allows you to control the Hybrid SLI function.
Options: Disabled (Default) / Enabled
Primary Graphics Adapter
This item allows you to choose the primary graphics device.
Options: PCIE VGA Card First (Default) / Intern al VGA First / PCI VGA Card
First
