GF8100 M2G+ BIOS Manual

MemClock Value

Options: 200MHz (Default) / 266 MHz / 333 MHz / 400 MHz /

533 MHz (with AM2+ CPU)

MCP PCI-Express Frequency, MHz

Options: 100 (MHz) (Default) / 100 ~ 200
