GF8100 M2G+ BIOS Manual
26
6 Performance Menu
This submenu allows you to change voltage and clock of various devices.
(However, we suggest you to use the default setting. Changing the voltage and clock
improperly may damage the device.)
Notice
z Beware of that setting inappropriate values in items of this menu may cause
system to malfunction.
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Chipset Performance
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
Performance Settings
WARNING: Setting wrong values in below sections
may cause system to malfunction.
> Over-Voltage Configuration
> DRAM Timing Configuration
> Spread Spectrum Configuration
> AMD Overclocking Configuration
Processor Frequency Multiplier [Auto]
SB to K8(CPU) Freq Auto [Enabled]
SB to K8(CPU) LinkWidth [16 16 ]
Memory Clock Mode [Auto]
Memclock Value [200MHz]
MCP PCI-Express Frequency, MH [100]
CPU Frequency, MHz [200]
z
Exit
Adjust Voltage
function.
