GF8100 M2G+ BIOS Manual
33
Core VID (for AM2+ CPU)
This function allows you to adjust the voltage of CPU.
Options: 0.0125V ~ 1.5500V (differs from CPU).
Core DID (for AM2+ CPU)
Options: Divided by 1 (Default) / Divided by 2 / Divided by 4 / Divided by 8 /
Divided by 16
NB FID (for AM2+ CPU)
This item allows you to select the Frequency of NB chip.
Options: 2000MHz (Default) / 800MHz ~ 7000MHz with an interval of 200MHz
NB VID (for AM2+ CPU)
This item allows you to select the voltage of NB chip.
Options: 0.0125V ~ 1.5500V (differs from CPU)
CPU Frequency, MHz
This item allows you to select the CPU Frequency.
Options: 200 (MHz) (Default) / 100 ~ 500
Processor Frequency Multiplier
This item allows you to control the CPU multiplier.
Options: Auto (Default) / x4 ~ x25 (differs by CPU)
SB to K8(CPU) Freq Auto
Options: Enabled (Default) / Disabled
SB to K8(CPU) LinkWidth
Options: 16↓16↑ (Default) / 8↓8↑ / 4↓4↑
Memory Clock Mode
This item allows you to control the Memory Clock.
Options: Auto (Default) / Limit / Manual
