![Biostar N68S+ Версия 6.x [38/47] Ortuguese](/views2/1711900/page38/bg26.png)
Motherboard Manual
36
PORTUGUESE
ESPECIFICAÇÕES
CPU
Socket AM2+
Processadores AMD Phenom / Pheno m II /
Athlon / Athlon II / Sempron
(Watt máximo: 95W)
A arquitectura AMD 64 p ermite uma co mputação de 32
e 64 bits
Suporta as tecnologias Hyper Transport e Cool’n’Quiet
FSB
Suporta a tecnologia HyperTransport com
uma largura de banda até1 GHz
Chipset
GeForce 6150 SE/nForce 430 (MCP6P M2+)
GeForce 7025/nForce 630a (N68S+)
Especificaçã
o Super I/O
ITE 8716F
Proporciona as funcionalidades mais
utilizadas em termos da especificação
Super I/O.
Interface LPC (Low Pin Count).
In ic iat ivas par a contro lo do amb iente
Monitorização do hardware
Controlador da velocidade da ventoinha
Função "S mart Guard ian" da ITE
Memória
principal
Ranhuras DIMM DDR2 x 2
Capacidade máx ima d e memór ia: 8 GB
Cada módulo DIMM suporta uma
memória DDR2 de 256 MB/512 MB &
1 GB/2 GB/4 GB
Módulo de memória DDR2 de canal duplo
Suporta módulos DDR2 533 / 667 / 800 / 1066
Os módulos DIMM registados e os DIMM ECC não são
suportados
Placa
gráfica
GeForce 6150 SE/nForce 430 (MCP6P M2+)
GeForce 7025/nForce 630a (N68S+)
Memória de vídeo máxima partilhada: 512 MB (under
OS)
IDE
Controlador IDE integrado
Modo Bus master Ultra DMA 33 / 66 / 100 / 133
Suporta o modo PIO 0~4,
SATA II
Controlador Serial ATA integrado
Velocidades de transmissão de dados até 3 Gb/s.
Compat ibilidade co m a especificação SATA versão 2.0.
LAN
Realtek RTL 8201CL
Auto negociação de 10 / 100 Mb/s
Capacidade semi/full-duplex
Codec de
som
ALC662
Saída de áudio de 5.1 canais
Suporta a especificação High-Definition Audio
Ranhura PCI x2
Ranhuras
Ranhura PCI Express x16 x1
Conector da unidade de disquetes x1 Cada conector suporta 2 unidades de disquetes
Conector da para impressora x1 Cada conector suporta 1 Porta para impressora
Conectores
na placa
Conector IDE x1 Cada conector suporta 2 dispositivos IDE
