Motherboard Manual
44
JAPANESE
仕様
CPU
Socket AM2+
AMD Pheno m / Phenom II / Athlon /
Athlon II / Sempron プロセッサ
(最高のワット: 95W)
AMD 64アーキテクチャでは、32ビットと64ビット計算が可
能です
ハイパートランスポートとクールアンドクワイアットをサポ
ートします
FSB
1GHzのバンド幅までハイパートランスポート
をサポートします
チップセット
GeForce 6150 SE/nForce 430 (MCP6P M2+)
GeForce 7025/nForce 630a (N68S+)
メインメモリ
DDR2 DIMMスロット x 2
最大メモリ容量8GB
各DIMMは 256MB/512MB & 1GB/2GB/
4GB DDR2をサポート
デュアル チャンネルモードDDR2メモリモジュール
DDR2 533 / 667 / 800 / 1066をサポート
登録済みDIMMとECC DIMMはサポートされません
Super I/O
ITE 8716F
もっとも一般に使用されるレガシーSuper I/O
機能を採用しています。
低ピンカウントインターフェイス
環境コントロールイニシアチブ、
H/Wモニター
ファン速度コントローラ/ モニター
ITEの「スマートガーディアン」機能
グラフィック
ス
GeForce 6150 SE/nForce 430 (MCP6P M2+)
GeForce 7025/nForce 630a (N68S+)
最大の共有ビデオメモリは512MBです(under OS)
IDE
統合IDEコントローラ
Ultra DMA 33 / 66 / 100 / 133バスマスタモード
PIO Mode 0~4のサポート、
SATA II
統合シリアルATA コントローラ
最高3 Gb/秒のデータ転送速度
SATAバージョン2.0仕様に準拠。
LAN
Realtek RTL 8201CL
10 / 100 Mb/秒のオートネゴシエーション
半/全二重機能
サウンド
Codec
ALC662
5.1チャンネルオーディオアウト
ハイデフィニションオーディオのサポート
PCIスロット x2
スロット
PCI Express x16スロット x1
フロッピーコネクタ x1 各コネクタは2つのフロッピードライブをサポートします
プリンタポートコネクタ x1 各コネクタは1つのプリンタポートをサポートします
オンボードコ
ネクタ
IDEコネクタ x1 各コネクタは2つのIDE デバイスをサポートします
