Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket AM2+
AMD Pheno m / Phenom II / Athlon /
Athlon II / Sempron processors
(Maximum Watt: 95W)
AMD 64 Architecture enables 32 and 64 bit computing
Supports Hyper Transport and Cool=n=Quiet
FSB
Supports up to 1 GHz Bandwidth
Support HyperTransport
Chipset
GeForce 6150 SE/nForce 430 (MCP6P M2+)
GeForce 7025/nForce 630a (N68S+)
Super I/O
ITE 8716F
Provides the most commonly used legacy
Super I/O functionality.
Low Pin Count Interface
Environment Control init iatives,
H/W Monitor
Fan Sp eed Contro ller
ITE's "S mart Guardian" function
Main
Memory
DDR2 DIMM Slots x 2
Max Memory Capacity 8GB
Each DIMM supports 256MB/512MB/1GB/
2GB/4GB DDR2
Dual Channel Mode DDR2 memory module
Supports DDR2 533 / 667 / 800 / 1066
Registered D IMM and ECC DIMM is not supported
Graphics
GeForce 6150 SE/nForce 430 (MCP6P M2+)
GeForce 7025/nForce 630a (N68S+)
Max Shared V id eo Memory is 512MB (under OS)
IDE Integrated IDE Contro ller
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4,
SATA II Integrated Serial ATA Controller
Data transfer rates up to 3 Gb/s.
SATA Version 2.0 specif icat ion co mp liant.
LAN Realtek RTL 8201CL
10 / 100 Mb/s auto negotiation
Half / Full duplex capability
Sound ALC662
5.1 channels audio out
High Definition Audio
PCI Slot x2 Supports PCI expansion cards
Slots
PCI Express x16 Slot x1 Supports PCI-E x16 expansion cards
Floppy Connector x1 Each connector supports 2 Floppy drives
Printer Port Connector x1 Each connector supports 1 Printer port
IDE Connector x1 Each connector supports 2 IDE device
SATA Connector x4 Each connector supports 1 SATA devices
On Board
Connector
Front Panel Connector x1 Supports front panel facilities
