Planet FTP-802 [10/22] Left view
![Planet FTP-802 [10/22] Left view](/views2/1071205/page10/bga.png)
9
Left View
There are one RJ-45 Twisted-Pair jack (Auto-MDI/MDI-X), one
ber-optic connector (vary by model) and four LED indicators.
PWR
TX RX
FX
TP
PoE
In Use
10/100Base-TX
PoE Media Converter
10/100Base-TX to 100Base-FX
LNK/
ACT
Right View
One DIP switch for Link Fault Pass Through (LFP) feature,
“ON” to turn-on the LLCF and LLR detection. And “OFF” to turn
–off this feature. Please refer to the following sections for more.
Also one DC 48V power socket for the PoE Media Converter.
48V DC
OFF
LFP
ON
