1. Overview

Thank you for purchasing PLANET FTP-80X family 10/100Mbps

Ethernet Twisted pair to 100Base-FX Fiber-optic PoE Bridge

Converter. This converter is used to convert one type media

signal to other type equivalent that allows two type segments

connect easily, efciently and inexpensively. The converter

provides Power over Ethernet power injector function which is

able to drive one IEEE 802.3af compliant powered devices.

About the Power over Ethernet Injector

The FTP-80X is an IEEE 802.3af Power over Ethernet Injector

that provide DC 48V over Ethernet cables. The FTP-80X IEEE

802.3af Power over Ethernet Injector inserts DC Voltage into

Cat.5 cable, allowing the cable between the Injector (FTP-

80X) and PoE PD (Powered Device) to transfer data and power

simultaneously. The maximum distance between the Injector

(FTP-80x) and PoE PD is 100 meters. With FTP-80x installed,

it is combines the Ethernet digital data with power over the

twisted pair cables as an IEEE 802.3af Power over Ethernet

Injector. And the IEEE 802.3af Power over Ethernet splitter shall

separate the digital data and the power into two outputs.

With IEEE 802.3af Power over Ethernet devices installed, the

system administrator only have to use a single RJ-45 Ethernet

cable to carries both power and data to each devices. Besides,

to connect through FTP-80x and PoE PD, you could also have

following benet that, cost saving, easy for networking planning

and higher reliability. What’s more, upon any IEEE 802.3af

devices installed, the FTP-80X or PD all can make the connection

while migrating and the Ethernet digital packets, such as

connecting the FTP-80X to an IEEE 802.3af complied devices,

AP or IP Camera.
