![Biostar NF4ST-A9 [3/64] Motherboard features](/views2/1712309/page3/bg3.png)
NF4ST-A9
1
CHAPTER 1: INTRODUCTION
1.1 MOTHERBOARD FEATURES
A. Hardware
CPU
Supports Socket 939.
Supports AMD Athlon 64 FX processor.
Supports AMD Athlon 64 processor.
Supports AMD Sempron processor.
AMD 64 architecture enables simultaneous 32 and 64 bit
computing.
Supports HyperTransport Technology.
Supports AMD Cool’n’Quiet Technology.
Chipset
NVIDIA nForce4 (CK8-04):
- Supports NVIDIA Firewall.
- Supports Gigabit Ethernet.
- Supports 10 USB 2.0 ports.
- Supports NVIDIA nTune Utility.
- Supports 1 PCI-Express x16 interface graphics slot.
- Supports 4 SATA ports, each channel up to 1.5Gb/s.
- Supports NVIDIA RAID functions, including RAID 0, RAID 1
and RAID 0+1.
- Supports 4 IDE disk drives with PIO Mode 5, Bride Mode
and Ultra DMA 33/66/100/133 Bus Master Mode.
- Compliant with AC’97 version2.3 specification.
- Complaints with PCI-Express Version 1.a specification.
Operating Systems
Supports Windows 2000 and Windows XP.
Note: Do not support Windows 98SE and Windows ME.
Supports SCO UNIX.
