Biostar NF4ST-A9 [8/64] Package checklist

NF4ST-A9

3 audio ports support 6 channels audio-out facilities.

(With ALC655, optional)

JKMBS1

PS/2

Mouse

PS/2

Keyboard

JPRNT1

JCOM1

JCOM2

(optional)

Printer Port

COM1

COM2

(optional)

J1394_USB1

1394 Port

(optional)

USB *2

JUSBLAN1

LAN

Connector

USB *2

Line-in/Rear

Line-out

MIC-in/

Center/

Left

B. BIOS & Software

BIOS

Award legal BIOS.

Supports APM1.2.

Supports ACPI.

Supports USB Function.

Bundled Software

Supports 9th Touch™, WINFLASHER™ and FLASHER™.

1.2 PACKAGE CHECKLIST

FDD Cable X 1

HDD Cable X 1

User’s Manual X 1

Fully Setup Driver CD X 1

Rear I/O Panel for ATX Case X 1

USB 2.0 Cable X1 (optional)

S/PDIF Cable X 1 (optional)

Serial ATA Cable X 1 (optional)

IEEE 1394 Cable X 1 (optional)

Serial ATA Power Switch Cable X 1 (optional)
