![Biostar NF4ST-A9 [6/64] Gigabit lan](/views2/1712309/page6/bg6.png)
NF4ST-A9
4
IEEE 1394A Chip (optional)
Chip: VIA VT6307.
Supports 2 ports with transfer up to 400Mb/s.
Gigabit LAN
NVIDIA Gigabit MAC + VITESSE Gigabit PHY VSC8201.
Supports 10 Mb/s, 100 Mb/s and 1Gb/s auto-negotiation.
Half/Full duplex capability.
Supports personal Firewall setup.
Supports ACPI power management.
Supports NVIDIA StreamThru technology
- Isochronous controller paired with Hyper Transport results
in fastest networking performance
Security
NVIDIA Firewall technology
- Native firewall solution
Advanced features
- Remote access, configuration, monitoring
- Command line interface (CLI)
- WMI scripts.
Storage
NVIDIA RAID Technology
- RAID 0 disk striping for highest system and application
performance
- RAID 1 disk mirroring support for fault tolerance
Support for both SATA and ATA-133 disk controller
standards
- RAID 0+1 disk striping and mirroring for highest
performance with fault tolerance
Internal On-board Connectors and Headers
1 audio-out header supports audio-out facilities.
1 front panel header supports front panel facilities.
1 CD-in connector supports CD-ROM audio-in function.
1 SPDIF-out connector supports digital audio-out function.
