access point network.
The wireless adapter must match the wireless mode of the access point it
associates to.
Wireless Mode
when Starting an
Ad Hoc Network
This mode allows selection of the channel the wireless adapter uses. The
channels available depend on the regulatory domain. If the adapter finds
no other ad hoc adapters, this selection specifies which channel with the
adapter starts the ad hoc network with.
The wireless adapter must match the wireless mode and channel of the
clients it associates to.
802.11a
Authentication
Mode
Select what mode the wireless adapter uses to authenticate to an access
point:
• Auto: causes the adapter to attempt authentication using
shared, but switches it to open authentication if shared fails.
• Open: enables an adapter to attempt authentication regardless
of its WEP settings. It will only associate with the access point if
the WEP keys on both the adapter and the access point match.
• Shared: only allows the adapter to associate with access points
that have the same WEP key.
For infrastructure (access point) networks, click the Preferred APs button to specify up to four
access points to which the client adapter should attempt to associate.
3.2.2 Modify a Profile
To modify a configuration profile, select the configuration from the Profile list and click the Modify button.
Please refer to above sections for detailed explanations about the settings.
3.2.3 Remove a Profile
To remove a configuration profile, select the configuration from the Profile list and click the Remove
button.
The WL-U357 utility only allows the creation of 16 configuration profiles. After the creation of 16 profiles,
clicking the New button displays an error message. Remove an old profile or modify an existing profile for
a new use.
