Planet WL-U357 [7/35] Specification
![Planet WL-U357 [7/35] Specification](/views2/1071288/page7/bg7.png)
Historical or old buildings, public occasions, venues and open area where it is difficult to wire.
3. Frequently changing environments
Factories, Retailers, and Offices that frequently change locations and rearrange the workplace
4. Temporary network access
Events, exhibitions, construction sites or some important occasions that require temporary
network access.
5. Access to database for mobile workers
Doctors, nurses, retailers, white-collar workers who need access to database while roaming in
the hospital, retail store or office.
6. SOHO (Small Office and Home Office) users
SOHO users who are in need of easy-to-install and wide coverage networking.
1.3 Specification
Attached Interface USB 2.0 A-type connector
Operating Frequency /
Channel
2.412~2.462GHz (FCC, Canada) / 11 Channels
2.412~2.472GHz (ETSI, Europe) / 13 Channels
2.412~2.484GHz (TELEC, Japan) / 14 Channels
Emission type
Direct Sequence Spread Spectrum (DSSS) Technology
RF Modulation
OFDM with BPSK, QPSK, 16QAM, 64QAM
RF Output Power 15dBm
Data Rate
802.11b: 1, 2, 5.5, 11Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54Mbps
Super G: up to 108Mbps
Security
64/128/152bit WEP
802.1x
WPA-PSK
WPA-RADIUS
Antenna Internal Patch Antenna
Sensitivity
IEEE802.11b:
2Mbps (QPSK): -87dBm
11 Mbps (QPSK): -82dBm
(Typically @PER < 8% packet size 1024 and @25ºC + 5ºC)
IEE802.11g:
54Mbps (64QAM): -66dBm
48Mbps (64QAM): -69dBm
36Mbps (16QAM): -74dBm
24Mbps (16QAM): -78dBm
18Mbps (QPSK): -82dBm
12Mbps (QPSK): -84dBm
3
