Chapter 2 Installation Procedure
Before you proceed with the installation, it is necessary that you have enough information about the
Wireless USB Adapter. Follow the procedure described below in this chapter to install the USB adapter
under Windows 98SE/ME/2000/XP.
2.1 Configuration Utility & Driver Installation
The following installation operates under Window XP. The procedure also applies to Windows
98SE/ME/2000.
Note 1: If you had ever installed the other Wireless Cards before, please uninstall the existed
drivers and utilities first.
Note 2: Please install the configuration utility before insert WL-U357 into the USB port of the
computer.
A. Insert the bundled CD into the CD-ROM drive to launch the autorun program. Once completed, a
menu screen will show up as follows.
B. Depending on the operating system you use, click on “For Windows 2000/XP” or “For Windows
98/ME” hyper link to initiate the installation procedure. You will see the below InstallShield Wizard
window. Please click “Next” to continue.
5
