Ariston C34SG37 [14/24] Installation

! Before operating your new appliance please read

this instruction booklet carefully. It contains

important information concerning the safe installation

and operation of the appliance.

! Please keep these operating instructions for future

reference. Make sure that the instructions are kept

with the appliance if it is sold, given away or moved.

! The appliance must be installed by a qualified

professional according to the instructions provided.

! Any necessary adjustment or maintenance must be

performed after the cooker has been disconnected

from the electricity supply.

Room ventilation

The appliance may only be installed in permanently-

ventilated rooms, according to current national

legislation. The room in which the appliance is

installed must be ventilated adequately so as to

provide as much air as is needed by the normal gas

combustion process (the flow of air must not be

lower than 2 m

/h per kW of installed power).

The air inlets, protected by grilles, should have a

duct with an inner cross section of at least 100 cm

and should be positioned so that they are not liable

to even partial obstruction (

see figure A

These inlets should be enlarged by 100% - with a

minimum of 200 cm

- whenever the surface of the

hob is not equipped with a flame failure safety

device. When the flow of air is provided in an

indirect manner from adjacent rooms (

see figure B

provided that these are not communal parts of a

building, areas with increased fire hazards or

bedrooms, the inlets should be fitted with a

ventilation duct leading outside as described above.

! After prolonged use of the appliance, it is

advisable to open a window or increase the speed of

any fans used.

Disposing of combustion fumes

The disposal of combustion fumes should be

guaranteed using a hood connected to a safe and

efficient natural suction chimney, or using an electric

fan that begins to operate automatically every time

the appliance is switched on (

see figure

! The liquefied petroleum gases are heavier than air

and collect by the floor, therefore all rooms

containing LPG cylinders must have openings

leading outside so that any leaked gas can escape

easily.

LPG cylinders, therefore, whether partially or

completely full, must not be installed or stored in

rooms or storage areas that are below ground level

(cellars, etc.). Only the

cylinder being used should be stored in the room;

this should also be kept well away from sources

of heat (ovens, chimneys, stoves) that may cause

the temperature of the cylinder to rise above 50°C.

Positioning and levelling

! It is possible to install the appliance alongside

cupboards whose height does not exceed that of the

hob surface.

! Make sure that the wall in contact with the back of

the appliance is made from a non-flammable, heat-

resistant material (T 90°C).

To install the appliance correctly:

• Place it in the kitchen, dining room or the bed-sit

(not in the bathroom).

• If the top of the hob is higher than the cupboards,

the appliance must be installed at least 200 mm

away from them.

• If the cooker is installed underneath a wall cabinet,

there must be a minimum distance of 420 mm

between this cabinet and the top of the hob.

This distance should be increased to 700 mm if

the wall cabinets are flammable (

see figure

Fumes channelled through

a chimney or branched

flue system reserved for

cooking appliances)

Installation

Adjacent room Room requiring

ventilation

Ventilation opening for

comburent air

Increase in the gap between

the door and the flooring

Fumes channelled

straight outside

We recommend cleaning the oven before

using it for the first time, following the

instructions provided in the "Care and

maintenance" section.
