Specifications
SST-RV02B-E (black)
SST-RV02B-EW (black + window)
Model
Material reinforced plastic outer shell, 0.8mm Steel body
SSI CEB, ATX (maximum 12” x 11”) , Micro ATX
Exposed 5.25" x 5
Internal 3.5" x 5 , 2.5” x1
Bottom 3 x 180mm intake fan 700/1200rpm, 18/34dBA
Top 1 x 120mm exhaust fan, 950rpm, 18dBA
7
USB 3.0 x 2, Audio x 1, MIC x 1
1 x optional standard PS2 (ATX)
212mm (W) x 503mm (H) x 643mm (D)
Up to 12.2 inch
Expansion Card
Motherboard
Matte black Color
Dimension
Drive Bay
Cooling System
Expansion Slot
Front I/O Port
Power Supply
SERIES
SERIES
Revolutionary 90 degree motherboard
mounting from RAVEN RV01
