SilverStone SST-RV02B-EW-USB3.0 [5/40] Disassemble chart
![SilverStone SST-RV02B-E [5/40] Disassemble chart](/views2/1713417/page5/bg5.png)
4
SERIES
SERIES
FRONT I/O Pin Definition
Disassemble Chart
RIGHT SIDE PANEL-W
18032 FAN x 3
PSU FILTER
18032 FAN SWICTH x 3
TOP COVER
12025 FAN
RESWT SW
FRONT I/O
POWER SW
5.25” DRIVE BAY x 5
SILVERSTONE SST-CP05
LIFT SIDE PANEL
PS2 PSU(OPTION)
ATX MB(OPTION)
180 FAN BRACKET
180 FAN FILTER
3.5” DEIVE BAY x 5
PACKAGE CONTENT
SCREW A
SCREW B
SCREW C
SCREW D
SCREW E
RADIATOR-BKT
BUNCH WIRE TIES
PSU BKT
2.5”HDD BKT
5.25” CHANGE 3.5PLATE
5.25” CHANGE 3.5BKT
BUNCH WIRE TIES
FAN CABLE
SECURE 5.25” DEVICE
SECURE HARD DRIVE
SECURE MOTHERBOARD
SECURE 5.25” DEVICE
SECURE RADIATOR
SECURE WIRE
SECURE POWER SUPPLY
SECURE 2.5”HARD DRIVE
SECURE FLOPPY
SECURE FLOPPY
SECURE POWER SUPPLY
SECURE FAN
SECURE POWER SUPPLY OR
PSU BKT AND MOTHRBOARD
